Crawler Compost Turner - Professional Windrow Composting Equipment | Yuxing Machinery

Yuxing's YXFD-2600 crawler compost turner offers high-performance composting, processing 800-1000m³/h. A powerful 85kW turbocharged diesel engine (116HP) powers this track-driven equipment, which can handle 2600mm wide and 1300mm high windrows. Our crawler design evenly distributes ground pressure, providing steady operation on soft, muddy, or uneven industrial composting facility terrain. Yuxing offers field-tested engineering and lifetime technical support with 20 years of manufacturing expertise and deployment in 50+ countries. The YXFD-2600 has six forward and two reverse gears, selectable working speeds of 0-15m/min, and an 860mm rotating drum that accelerates aerobic fermentation, decreasing composting cycles by 30% compared to manual turning.

How It Works: The Science Behind Efficient Windrow Turning

The product works via mechanical aeration and intense mixing. Long windrows of livestock dung, municipal sludge, or agricultural wastes are placed on an open composting pad.

The dual-track chassis moves the machine down the windrow. The high-speed revolving drum with wear-resistant manganese steel teeth penetrates the pile at 0-20m/min. Revolutions lift, tumble, and redistribute materials, delivering oxygen to the windrow and breaking up heat- and moisture-trapped zones.

This rigorous mixing yields three crucial results. It fluffs the pile to generate air spaces for aerobic microorganisms to decompose quickly. Second, it prevents anaerobic hot spots by homogenizing moisture content by circulating wet and dry zones. Third, cold inner layers are exposed to ambient air to maintain thermophilic conditions (55-65°C) that kill diseases and weed seeds.

An ergonomic cab lets your operator modify travel speed and drum rotation dependent on pile density and wetness. Compost maturity is uniform across the batch, processing times are faster, and customers get a better product.

Technical Specifications: Built for Heavy-Duty Industrial Use

Key Advantages: Why Choose Yuxing Tracked Turners?

Superior Traction and Stability

The dual-track chassis prevents wet-weather sinkage by spreading machine weight across a broad contact area. You may keep rotating schedules after severe rain, when wheeled equipment would bog down or damage your composting pad.

Massive Processing Power

The YXFD-2600 is ideal for large-scale operations such as municipal composting, industrial animal farms, and centralized organic waste treatment plants, with a potential capacity of 800-1000m³/h. You windrow more per shift, lowering labor expenses and speeding inventory turnover.

Flexible Material Handling

From fibrous agricultural leftovers to high-moisture chicken manure and thick municipal sludge, our crawler compost turner handles particle sizes up to 250mm. Strong, clumped materials would halt lighter machines, but the high-torque drive system pushes through them.

Durable Engineering for Continuous Use

Manganese steel rotating teeth deflect sand and grit. The crawler undercarriage can handle tough terrain for long periods. All important components undergo Chinese technical and quality supervision bureau testing, assuring dependability in tough manufacturing situations.

Operator Safety and Comfort

The covered cab protects the operator from bio-aerosols, dust, and stink. Travel and drum speeds are precisely adjusted using intuitive controls. Hydraulic systems with low vibration prevent operator fatigue during long shifts.

Flexible Customization and Fast Delivery

Stocked standard units ship instantly. CE certification, Siemens PLC integration, multi-language HMI, voltage adaptation—custom configurations—take 15-20 days. We support ODM/OEM branding and customize equipment for area regulations and manufacturing.

Application Scenarios: Proven Performance Across Diverse Industries

Municipal Sludge Composting

Our tracked turner processes dewatered sewage sludge with woodchips or sawdust in wastewater treatment plants. The machine maintains thermophilic temperatures to aerate viscous, high-moisture materials, neutralizing microorganisms.

Big-scale livestock waste management

Industrial poultry, dairy, and swine businesses produce tons of manure everyday. High-frequency turning schedules over numerous windrows recycle animal manure into marketable organic fertilizer while managing odor and fly populations with the YXFD-2600.

Recycling Agricultural Waste

Sugar mills, cotton gins, and food processors utilize our product to enrich soil with bagasse, cottonseed hulls, and vegetable trimmings. Durable drums pierce fibrous, thick, non-decomposing materials.

Prepare Mushroom Substrate

Our equipment's consistent mixing and moisture distribution benefits mushroom farms processing wasted substrate or conditioning fresh compost. Higher mushroom yields and decreased disease incidence result from consistent substrate quality.

Industrial Organic Fertilizer Production

Yuxing technology provides consistent throughput, product quality, and low downtime for compost manufacturers that provide bulk organic fertilizer to agricultural and landscaping.

Quality Control: Rigorous Testing for Reliable Field Performance

Yuxing tracked turners are thoroughly inspected before shipment. To prevent leaks, hydraulic lines are pressure-tested to 1.5× working capacity. Laser-precise dynamic balance on the revolving drum prevents structural wear.

Turning teeth are tested for abrasive wear resistance using Rockwell hardness (HRC). To avoid derailing during high-torque movements, track tension and alignment are evaluated. Finally, four-hour continuous load tests verify thermal management, keeping hydraulic fluid and engine coolant at ideal temperatures in tropical climes.

All equipment fulfills ISO 9001 and optional CE labeling for Europe. Chinese provincial agricultural machinery assessment stations have recognized our compost turners for government subsidy schemes, demonstrating our safety and performance.

Our engineers provide complete inspection reports, operator manuals in your language, and installation instructions. Lifetime technical support—installation, remote troubleshooting via video, spare parts consulting, and production optimization advice—ensures your investment is worthwhile.

FAQ

Q: Why is a product better than a wheeled model for outdoor operations?

A: The crawler track distributes machine weight over a larger surface area, preventing sinkage in wet soil and providing necessary traction through heavy, dense windrows. This design ensures uninterrupted operation regardless of weather conditions.

Q: What is the typical replacement cycle for the turning teeth?

A: Depending on material abrasiveness (sand content, for example), high-quality manganese teeth typically last 800-1,200 operating hours. We supply replacement teeth as part of our aftermarket support.

Q: Can the YXFD-2600 handle moisture content above 60%?

A: Yes, the high-torque design breaks up heavy, wet clumps. However, we recommend adding bulking agents like sawdust or straw to optimize aerobic conditions and shorten fermentation time.

Q: What kind of fuel efficiency can I expect?

A: Modern tracked turners use load-sensing hydraulic systems that adjust power output based on pile resistance. Average consumption ranges from 15-35 liters per hour, depending on material density.

Q: How does the machine protect the operator from bio-aerosols?

A: Professional units feature pressurized, air-conditioned cabs with HEPA filtration systems, ensuring a safe, odor-free working environment during extended shifts.

Q: What after-sales support does Yuxing provide?

A: We offer lifetime technical assistance—factory planning, installation guidance, operator training, remote video troubleshooting, spare parts supply, and production optimization. Our 24/7 global support team responds promptly to keep your operation running smoothly.
